xTool X1 laser cutter & engraver review

The xTool X1 laser cutter and engraver presents itself as a large, enclosed machine, but it quickly becomes evident that it is far more ambitious than a typical laser engraver. Essentially, xTool has merged years of laser engraving development into a single, expandable manufacturing platform, making the X1 one of the most versatile machines the reviewer has ever encountered.

At the heart of the X1 is a 55W CO₂ laser, similar to that found in the Bambu Lab R1, although the X1 is larger and priced similarly, promising substantial potential. This powerful laser excels at cutting and engraving wood, acrylic, and a wide range of other materials.

However, the X1's true versatility lies in its dual head system. xTool has incorporated an optional 20W diode galvo module, which works alongside the CO₂ laser. The galvo system is particularly adept at intricate, high-speed engraving, while the CO₂ laser handles cutting tasks. Both systems are controlled through xTool Studio, allowing the user to switch between the installed lasers with just a selection option in the software.

This combination enables the X1 to complete projects such as wooden placemats and detailed pencil boxes much faster than would be possible with a single laser system.

The X1's design also supports additional laser-source modules mounted on the rear of the machine. The reviewer tested the 5W UV and 60W MOPA modules, which allowed them to engrave glass and emboss brass coins. They also used the MOPA for creating precision apertures in thin metal for pinhole cameras. While the results were impressive, the reviewer noted that the machine's size, weight, and complexity required careful consideration when installing and swapping modules.

Accessing the rear of the machine for module changes and recalibrating took approximately an hour, which could be a significant factor for users who need to switch between different laser technologies frequently.

The X1 comes with a price tag of $3,699 / £2,553 for the base machine featuring the 55W CO₂ laser. However, the costs can quickly escalate with optional modules. The 20W diode galvo module alone costs $899 / £674, and a fully equipped system, including the base machine and various optional modules, can reach nearly $10,000 when purchased separately.

Despite the higher price, the reviewer finds the X1 to be a capable and versatile machine, capable of general cutting, detailed engraving, and small-batch production. It stands out as one of the most refined laser engravers the reviewer has used, making it an excellent choice for those with an established workshop, small business, or a range of materials to work with.
